4" 2/3-JAW DOUBLE ENDED MECHANICAL PULLER

  • Model: KEN-503-3240K
  • Shipping Weight: 1.29kg
  • Manufactured by: KENNEDY

RM193.60

Add to Cart:
Model : KEN5033240K
Mechanical Bearing Pullers - 2/3 Jaw

Industrial reversible / double-ended adjustable pullers.
Used for the removal of gears, ball races, bearings, pulleys and sprockets from a drive shaft. With reach capacities of 75, 100, 150 and 200mm.
All sizes have double-ended, adjustable, reversible legs and can be used for internal and external applications.
Selection: Always use a three jaw puller whenever possible. This produces better load distribution across the jaws and easier and safer removal of the part.
Determine what 'spread' is needed - this is the width of the part to be removed. The reach capacity is determined by the depth of the part to be removed.

All pullers can be assembled for internal or external use.

Combined 2+3 Jaw Pullers - '4-in-1'
Supplied with 2 and 3-legged yokes and 3 leg assemblies - allowing the pullers to be configured in 2 jaw internal / external or 3 jaw
internal / external assemblies.

Specification

Property Value
Brand Kennedy
EAN13 Barcode 5036140003903
eCl@ss Code 21043090
Overall Depth 30
Overall Length 365
Overall Weight 1.29
Overall Width 210
Reach 100 mm
Spread 40 - 87 mm
Supplier Part No. 5033240K
Thread Length 100 mm
UNSPSC Code 27111712

Further Information

Property Value
Capacity 50 to 100 mm millimetre in. inch
Maximum Diameter mm millimetre
Product Number
Product Type Puller
Reach 70 mm millimetre
Spread 50 - 100 mm millimetre
Thread Length 160 mm millimetre
To Suit
Weight Each 1.29 kg kilogram
Number of Pieces 1
Includes 1 x 2-legged yoke
1 x 3-legged yoke
1 x thrust bolt
3 x leg assemblies
Minimum Diameter mm millimetre
Additional Features Can be used for internal and external applications
Double-ended, adjustable, reversible legs
Number of Jaws 2
3
Jaw Reach 70 mm millimetre


This product was added to our catalog on Monday 17 May, 2010.
