PROSKIT MT-1705 3 1/2 Compact Digital Multimeter

  • Model: MT-1705
  • Shipping Weight: 0.15kg
  • Manufactured by: PRO'SKIT

Sold Out

ITEM DISCONTINUED

Model : PROSKIT MT-1705 3 1/2 Compact Digital Multimeter

Description


MT-1705 is a 3 1/2 Compact Digital Multimeter with 1999 counts, which able to accurately test and measure different parameters within an electrical circuit for a wide variety of electrical and electronic applications.


Features


  • 3 1/2 digits 1999 counts.
  • 0.5% best accuracy.
  • CAT III 600V safety rated.
  • Auto polarity indication.
  • AC True-RMS for accurate measurements.
  • Extra function: continuity with beeper, diode test, data hold, auto power off, low battery indication, overload indication, LCD backlight.
  • Frequency and capacitance are auto range.
  • Ideal for wide variety of electrical and electronic testing applications.


Specifications


DC Voltage (V)

200mV/2V/20V/200V±(0.5%+3d) ,600V±(1.0%+10d)

AC Voltage (V)
True-RMS

40Hz-200Hz and 200Hz-1kHz sine and triangular wave:
2V/200V±(0.8%+5d), 600V±(1.2%+10d)

200Hz-1kHz other wave: 2V/200V/600V±(8.0%+15d)

DC Current (A)

20mA/200mA±(1.2%+8d),10A±(2.0%+5d)

AC Current (A)
True-RMS

40Hz-200Hz and 200Hz-1kHz Sine and triangular wave:
200mA±(1.5%+15d),10A±(3.0%+10d)

200Hz-1kHz Other wave: 200mA/10A±(8.0%+15d)

Resistance (Ω)

200±(0.8%+5d), 20K/200K±(0.8%+3d), 20M±(1.0%+25d)

Frequency (Hz)

10/100/1k/10k/100k/2M Hz±(1.0%+10d)

Capacitance (F)

20nF/200nF/2uF±(3.5%+20d), 20uF/200uF/2000uF±(5.0%+10d)

Power source

3V(1.5VAAA×2) (Not included)

Size (mm)

150×73.5×35 mm

Individual Packing

150×73.5×35 mm
