Display : 4000 counts.

•

Auto range.

•

Diode test feature.

•

Capacitance test feature.

•

Continuity test.

1 year warranty

DC V

400mV/4/40/400/600V (Input Impedance 10MΩ)
|±0.8%rdg±5dgt (400mV/4/40/400V)
|±1.0%rdg±5dgt (600V)

AC V

4/40/400/600V (Input Impedance 10MΩ)
|±1.3%rdg±5dgt (4/40V)
|±1.6%rdg±5dgt (400/600V)

Frequency

10/100Hz/1/10/100/200kHz

Ω

400Ω/4/40/400kΩ/4/40MΩ
|±1.0%rdg±5dgt (400Ω/4/40/400kΩ/4MΩ)
|±2.5%rdg±5dgt (40MΩ)

Diode Test

4V Release Voltage:Approx. 0.4mA Test Current

Capacitance Test

4nF/40nF/400nF/4µF/40µF/200µF

Continuity buzzer

400Ω (Buzzer sounds below 120Ω)

Withstand Voltage

3700V AC for 1 minute

Applicable standards

IEC 61010-1 CAT.III 300V
IEC 61010-2-031
IEC 61326-1

Power Source

LR44 (1.5V) × 2

Dimensions

107(L) × 54(W) × 10(D)mm (11.2cm x 16.9cm x 1.7cm)

Weight

70g approx.

Accessories

LR44× 2
Instruction Manual
1018 (Soft Case)
1018H (Hard Case)
