Kyoritsu 3005A Insulation/Continuity Tester

  • Model: KE 3005A
  • Shipping Weight: 1.37kg
  • Manufactured by: KYORITSU


Add to Cart:

Image result for ready stock

Bargraph to display insulation resistance.

Displays the value of external AC voltage along with flashing symbol.

Auto null function to automatically subtract the test lead resistance before displaying the real continuity resistance value.

Live circuit warning beeper.

Releasing the test button automatically discharges the charges stored in the circuit under test.

200mA continuity measuring current to IEC 61557.

Minimum 1mA current on insulation tests to IEC 61557.


 Diamension : 21.5cm x 21.8cm x 9.2cm

Insulation Resistance

Test Voltage


Measuring Ranges
(Mid-scale Value)


Output Voltage
on open circuit

Rated test voltage+20%, -0%

Nominal Current

1mA DC min.

Output Short
Circuit Current

1.5 mA DC approx.


|±1.5%rdg±5dgt (20MΩ/200MΩ)
|±10%rdg±3dgt (2000MΩ)

Continuity Test

Measuring Ranges
(Mid-scale Value)


Output Voltage
on open circuit

7~12V DC

Measuring Current

200mA DC min.


|±1.5%rdg±5dgt (20Ω)
|±1.5%rdg±3dgt (200Ω/2000Ω)

AC Voltage

AC Voltage range

0-600V AC




Safety Standard

IEC 61010-1 CAT.III 300V Pollution Degree 2
IEC 61010-2-031 IEC 61557-1/2/4

IP Rating

IEC 60529-IP54

EMC Standard

IEC 61326-1

Withstand Voltage

3700V AC for 1 minute

Power Source

R6P (AA) (1.5V) × 8


185(L) × 167(W) × 89(D)mm


970g approx


7122B (Test leads) Pouch for test leads
8923 (F500mA/600V fuse) × 2
R6P (AA) × 8, Shoulder Strap
Instruction Manual
